Scope of Application
Mainly used for bacteria, algae and other observation, suitablefor aquaculture, sewage plants, etc., cost-effective.
ProductDetails:
Model | TOP-C2101 |
Magnification | 40x-1600x |
Eyepiece | wide-angle eyepiece WF10X(Φ18mm) |
wide-angle eyepiece WF16X(Φ10mm) |
Objective: | infinity plan achromatic objective 4X |
infinity plan achromatic objective 10X |
infinity plan achromatic objective 40X/(spring) |
infinity plan achromatic objective 100X/(spring, oil) |
Eyepiece Len | hinge type Trinocular,30° incline,360° rotate , interpupillary distance range 55-75mm |
Focus arm | coarse and fineadjustment, coarse adjust 22mm,fine adjust 0.002mm |
Nosepiece | Quadripuntal (Introverted type ball location) |
Working stage | Double layer machinery moving stage,size:132mmX142mm |
Abbe condenser | N.A.=1.25 rise and down, with changeable diaphragm |
Illuminator | Critical illuminator |
Switch, voltage :AC 100V-250V |
Application | Bio field, wastewater treatment, bacterial detection ,breed aquatics etc. |
